# NTU – EE5704 Notes Run-Length Encoding

Run-Lenght Encoding is: instead of saying “apple apple apple pear pear banana orange orange apple”, you simpily say “Three apples, two pears, one banana, two oranges, and one apple. RLE is as simple as that.

Of course, in the world of digital computers you don’t count apple, pears or bananas. Digital computer use 0 and 1 to represent everything, so you count 0 and 1 instead. And the following is a simple and real world run-length encoding example

Run-length encoding (RLE) is a very simple form of data compression in which runs of data (that is, sequences in which the same data value occurs in many consecutive data elements) are stored as a single data value and count, rather than as the original run.

run length encoding algorithm is fairly simple and straight forward to implement and that’s the becauty of run length encoding compression.

## Run Length Encoding Examples

Run Length Encoding Algorithm Matlab Implementation

function encoded = RLE_encode(input)

my_size = size(input);
length = my_size(2);

run_length = 1;
encoded = [];

for i=2:length
if input(i) == input(i-1)
run_length = run_length + 1;
else
encoded = [encoded input(i-1) run_length];
run_length = 1;
end
end

if length > 1
% Add last value and run length to output
encoded = [encoded input(i) run_length];
else
% Special case if input is of length 1
encoded = [input(1) 1];
end

Run Length Decoding Java Example Code

public class RunLength{
private final static int R = 256; //max run length count
private final static int lgR = 8; //number of bits per count

public static void expand(){
boolean bit = flase;
while(!BinaryStdIn.isEmpty()){
for (int i=0; i<run; i++){
BinaryStdOut.write(bit); //write 1 bit to stdout
}
bit = !bit;
}
BinaryStdOut.close(); //pad 0s for byte alignment
}
}

Run-Length Coding Interactive Visual Demo
http://demonstrations.wolfram.com/BinaryRunLengthEncoding/

Run-Length Coding Video
